NS-SFP‑10G‑TX Transceiver Module | 10Gbps, RJ45, 30 m/100 m – Compatible with Major Brands

The NSComm NS-SFP‑10G‑TX is a flexible and economical Small Form‑Factor Pluggable Plus (SFP+) copper transceiver designed for 10 Gigabit Ethernet connectivity over twisted‑pair cabling.

It supports transmission rates up to 10 Gbps, using a standard RJ45 connector, and accommodates link distances up to 30 m over Cat6a/Cat7 or up to 100 m at lower speeds (1Gbps/100Mbps) over Cat5e/6 cables.

This module is hot‑swappable, ensuring painless in-field installation or upgrades without shutting down the system. It conforms to IEEE Ethernet standards and SFP+ MSA protocols. Some models may not support Digital Optical Diagnostic Monitoring (DOM).

Compatible Brands

The NS-SFP-10G-TX is universally compatible across all brands. If you need to verify compatibility with your specific switch model, please click Contact Us Now for assistance.

Key Specifications

Specification	Details
Vendor Name	NSComm
Form Factor	SFP+ (Small Form‑Factor Pluggable Plus)
Max. Data Rate	10 Gbps (also supports 1 Gbps and 100 Mbps)
Connector	RJ45
Max. Cable Distance	30 m at 10 Gbps over Cat6a/Cat7; 100 m at lower speeds
Media	Copper twisted-pair cabling
DOM Support	Optional (varies by vendor)
Power Consumption	Up to ~2.5 W
Operating Temperature Range	0 °C to 70 °C (Commercial)
Protocols Compliance	IEEE 802.3an, IEEE 802.3ab, IEEE 802.3u, SFP+ MSA

More Details

Quality Certifications

Do you have any question about the NSComm NS-SFP-10G-TX Optical Transceiver?

Please Chat with us now!

or leave us an message on sales@network-switch.com

Warranty

100% Low Price Guarantee

Network-switch.com provides high-quality products at low wholesale prices

100% Quality Assurance

All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Certified CCIE / HCIE / RCNP Engineers.

Free Technical Support

Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.

100% Money Back Guarantee

You can contact our customer service team to exchange or return any product that you bought from us.

Standard Warranty Policy

Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year

The Support Contacts

If your NSComm products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
